领先同行的Skyworks携Si5332晶振王者归来

2023-09-19 16:59:55

Skyworks晶振

Skyworks’ Timing Solutions Meet Next-Generation PCIe Requirements Si5332 Clock Family Supports Industry Transition to PCIe 6.0

Skyworks Solutions, Inc. (Nasdaq: SWKS), today announced the evolution of its Si5332 family of high-performance clock generators, supporting the industry transition to PCI Express Generation 6 (PCIe 6.0). According to PCI-SIG, new applications including artificial intelligence, machine learning and edge computing are driving the need for higher performance and increased bandwidth interconnects for compute, switching and storage platforms in data centers1. The Si5332 product family from Skyworks supports PCIe 6.0 while maintaining backwards compatibility with older PCIe standards.
“PCIe 6.0 is the future of the data center, and Skyworks is helping IC suppliers design with confidence when they make the transition to the latest PCIe standard,” said James Wilson, vice president and general manager of timing products at Skyworks. “Drawing from our decades of expertise in providing high-performance, low-jitter timing solutions for high-speed serial interconnect applications, we have qualified our Si5332 family to provide reference timing for the newest PCIe 6.0 applications.”
PCIe 6.0 increases data rates to 64GT/s and enables bandwidths as high as 256Gbps, effectively doubling the performance of PCIe 5.0. This latest upgrade to the PCIe standard ensures the high-speed interconnects used in data center applications do not become a bottleneck and complements the industry’s transition to 400G and 800G Ethernet. Unlike prior generations of the PCIe standard that used NRZ signalling, PCIe 6.0 uses PAM4 modulation to combine two bits into a single symbol with four amplitude levels. This approach doubles the transfer speed but degrades the eye diagram by replacing a single, large data eye with three smaller data eyes. Using a low jitter PCIe reference clock maximizes the PAM4 data eye opening and minimizes bit-error rate, which is necessary for faster transfer speeds.
The Si5332’s any-frequency clock synthesis, low jitter operation and support for PCIe 6.0 makes it ideally suited to replace fixed function oscillators, clocks and buffers with a single IC. The device features Skyworks proprietary MultiSynthTM fractional divider technology, which provides any-frequency synthesis and excellent jitter performance. The Si5332 is available in 6, 8 and 12-output options, with support for integrated format/level translation, LVPECL, LVDS, HCSL and LVCMOS, and 1.8-3.3V VDDO operation. When combined with support for PCIe 6.0, the Si5332 is well suited to operate as a data center clock-tree-on-a-chip, replacing multiple timing components with a highly integrated, high-performance solution. Device samples are available now.
In addition to this Si5332 product announcement, Skyworks is pleased to announce PCIe 6.0 support in its PCIe Jitter Tool. Long regarded as the industry standard for measuring PCIe clocks and evaluating compliance to PCIe jitter specs, the PCIe Jitter Tool now allows users to take accurate jitter measurements on PCIe 6.0 reference clocks.

Skyworks的计时解决方案符合下一代PCIe的要求,Si5332时钟系列支持向PCIe 6.0的行业过渡

Skyworks解决方案公司。(纳斯达克代码:SWKS),今天宣布其Si5332系列有源晶体高性能时钟发生器的演进,支持向PCI Express第6代(PCIe 6.0)的行业过渡。根据PCI-SIG的说法,包括人工智能、机器学习和边缘计算在内的新应用正在推动数据中心计算、交换和存储平台对更高性能和更高带宽互连的需求1。来自的Si5332石英晶振产品系列Skyworks支持PCIe 6.0,同时保持向后兼容旧的PCIe标准。
“PCIe 6.0是数据中心的未来,而且Skyworks帮助IC供应商在过渡到最新的PCIe标准时充满信心地进行设计。”詹姆士·威尔森,副总裁兼计时产品总经理Skyworks。“凭借我们数十年来为高速串行互连应用提供高性能、低抖动时序解决方案的专业经验,我们已经证明我们的Si5332贴片晶振系列能够为最新的PCIe 6.0应用提供参考时序。”
PCIe 6.0将数据速率提高到64GT/s,带宽高达256Gbps,有效地将PCIe 5.0的性能提高了一倍。这一对PCIe标准的最新升级确保了数据中心应用中使用的高速互连不会成为瓶颈,并补充了行业向400G和800G以太网的过渡。与使用NRZ信令的前几代PCIe标准不同,PCIe 6.0使用PAM4调制将两个比特组合成具有四个幅度级别的单个符号。这种方法将传输速度提高了一倍,但通过用三个较小的数据眼代替一个较大的数据眼,降低了眼图的质量。使用低抖动PCIe参考时钟可以最大化PAM4数据眼图张开度,并最小化误码率,这对于更快的传输速度是必要的。
Si5332的任意频率时钟合成、低抖动操作和对PCIe 6.0的支持使其非常适合用单个IC取代固定功能振荡器、时钟和缓冲器。设备功能Skyworks专有多合成铥小数分频器技术,提供任意频率合成和出色的抖动性能。Si5332提供6路、8路和12路输出选项,支持集成格式/电平转换、石英晶体振荡器LVPECL、LVDS、HCSL和LVCMOS以及1.8-3.3V VDDO工作电压。结合对PCIe 6.0的支持,Si5332非常适合用作数据中心的片上时钟树,用高度集成的高性能解决方案取代多个时序元件。器件样片现已上市。
除了本次Si5332产品发布之外,Skyworks很高兴宣布PCIe 6.0在其PCIe抖动工具。长期以来,PCIe抖动工具一直被视为测量PCIe时钟和评估是否符合PCIe抖动规范的行业标准,现在用户可以在PCIe 6.0参考时钟上进行精确的抖动测量。


晶振料号 品牌 系列 频率 输出 电压
535AC100M000DG Skyworks晶振 Si535 100 MHz LVPECL 3.3V
535AB125M000DGR Skyworks晶振 Si535 125 MHz LVPECL 3.3V
535FB125M000DG Skyworks晶振 Si535 125 MHz LVDS 2.5V
536BB125M000DG Skyworks晶振 Si536 125 MHz LVDS 3.3V
536FB125M000DG Skyworks晶振 Si536 125 MHz LVDS 2.5V
535FB156M250DG Skyworks晶振 Si535 156.25 MHz LVDS 2.5V
536FB156M250DG Skyworks晶振 Si536 156.25 MHz LVDS 2.5V
535AC106M250DG Skyworks晶振 Si535 106.25 MHz LVPECL 3.3V
536AB156M250DG Skyworks晶振 Si536 156.25 MHz LVPECL 3.3V
535BB156M250DG Skyworks晶振 Si535 156.25 MHz LVDS 3.3V
536BB156M250DG Skyworks晶振 Si536 156.25 MHz LVDS 3.3V
535AC156M250DG Skyworks晶振 Si535 156.25 MHz LVPECL 3.3V
536AC125M000DG Skyworks晶振 Si536 125 MHz LVPECL 3.3V
536AC156M250DG Skyworks晶振 Si536 156.25 MHz LVPECL 3.3V
535BC159M375DGR Skyworks晶振 Si535 159.375 MHz LVDS 3.3V
535BC312M500DGR Skyworks晶振 Si535 312.5 MHz LVDS 3.3V
535FB000172DGR Skyworks晶振 Si535 166.6286 MHz LVDS 2.5V
535FB000175DGR Skyworks晶振 Si535 167.3316 MHz LVDS 2.5V
535FB000292DGR Skyworks晶振 Si535 161.1328 MHz LVDS 2.5V
535FB000305DGR Skyworks晶振 Si535 156.2578 MHz LVDS 2.5V
535FB106M250DGR Skyworks晶振 Si535 106.25 MHz LVDS 2.5V
535FB150M000DGR Skyworks晶振 Si535 150 MHz LVDS 2.5V
535FB155M520DGR Skyworks晶振 Si535 155.52 MHz LVDS 2.5V
535FB159M375DGR Skyworks晶振 Si535 159.375 MHz LVDS 2.5V
535FB212M500DGR Skyworks晶振 Si535 212.5 MHz LVDS 2.5V
535FB312M500DGR Skyworks晶振 Si535 312.5 MHz LVDS 2.5V
535FC000172DGR Skyworks晶振 Si535 166.6286 MHz LVDS 2.5V
535FC000175DGR 有源晶振 Si535 167.3316 MHz LVDS 2.5V
535FC000305DGR Skyworks晶振 Si535 156.2578 MHz LVDS 2.5V
535FC106M250DGR Skyworks晶振 Si535 106.25 MHz LVDS 2.5V
535FC150M000DGR Skyworks晶振 Si535 150 MHz LVDS 2.5V
535FC155M520DGR Skyworks晶振 Si535 155.52 MHz LVDS 2.5V
535FC156M250DGR Skyworks晶振 Si535 156.25 MHz LVDS 2.5V
535FC159M375DGR Skyworks晶振 Si535 159.375 MHz LVDS 2.5V
535FC212M500DGR Skyworks晶振 Si535 212.5 MHz LVDS 2.5V
535FC312M500DGR Skyworks晶振 Si535 312.5 MHz LVDS 2.5V
536BB000172DGR Skyworks晶振 Si536 166.6286 MHz LVDS 3.3V
536BB000175DGR Skyworks晶振 Si536 167.3316 MHz LVDS 3.3V
536BB106M250DGR Skyworks晶振 Si536 106.25 MHz LVDS 3.3V
536BB150M000DGR Skyworks晶振 Si536 150 MHz LVDS 3.3V
536BB155M520DGR Skyworks晶振 Si536 155.52 MHz LVDS 3.3V
536BB159M375DGR Skyworks晶振 Si536 159.375 MHz LVDS 3.3V
536BC000172DGR Skyworks晶振 Si536 166.6286 MHz LVDS 3.3V
536BC000175DGR Skyworks晶振 Si536 167.3316 MHz LVDS 3.3V
536BC000292DGR Skyworks晶振 Si536 161.1328 MHz LVDS 3.3V
536BC000305DGR Skyworks晶振 Si536 156.2578 MHz LVDS 3.3V
536BC106M250DGR Skyworks晶振 Si536 106.25 MHz LVDS 3.3V
536BC155M520DGR Skyworks晶振 Si536 155.52 MHz LVDS 3.3V
536BC159M375DGR Skyworks晶振 Si536 159.375 MHz LVDS 3.3V
536BC312M500DGR Skyworks晶振 Si536 312.5 MHz LVDS 3.3V
536FB000172DGR Skyworks晶振 Si536 166.6286 MHz LVDS 2.5V
536FB000175DGR Skyworks晶振 Si536 167.3316 MHz LVDS 2.5V
536FB000292DGR Skyworks晶振 Si536 161.1328 MHz LVDS 2.5V
536FB000305DGR Skyworks晶振 Si536 156.2578 MHz LVDS 2.5V
536FB106M250DGR Skyworks晶振 Si536 106.25 MHz LVDS 2.5V
536FB150M000DGR Skyworks晶振 Si536 150 MHz LVDS 2.5V
536FB155M520DGR Skyworks晶振 Si536 155.52 MHz LVDS 2.5V
