9HT12-32.768KDZY-T,1610晶振,RTC实时时钟晶振

当前位置：首页 » 台产晶振 » 9HT12-32.768KDZY-T,1610晶振,RTC实时时钟晶振

prevnext

9HT12-32.768KDZY-T,1610晶振,RTC实时时钟晶振

频率：32.768K

尺寸：1610

9HT12-32.768KDZY-T,1610贴片晶振,RTC实时时钟晶振,32.768kHz标准计时频率,1.6×1.0mm超小贴片尺寸,解决轻薄数码产品空间紧缺痛点.电气指标标准化,25℃基础频差±20ppm,工作温度覆盖零下40至85摄氏度,高低温环境下频率偏移可控,保障全天候精准计时.晶体内部精密调校,ESR参数控制严苛,降低MCU计时电路驱动负担,适配纽扣电池供电低功耗设备.金属屏蔽封装具备一定抗干扰能力,可抵御主板微弱电磁干扰.

订购热线：0755-27838351

9HT12-32.768KDZY-T,1610晶振,RTC实时时钟晶振

9HT12-32.768KDZY-T为1610晶振微型贴片,标准32.768kHz时钟晶振频率,专为RTC实时时钟晶振电路定制,尺寸仅1.6×1.0×0.5mm,超轻薄封装适配小型化设备PCB布局.产品常温精度±20ppm,负载电容6pF,串联ESR数值低,驱动功耗极小,适配各类低功耗计时芯片.内置高稳定音叉晶体,温度漂移控制优秀,常规工作温区-40℃~85℃,温变下走时误差微弱.气密金属封装防潮抗尘,抗跌落,抗轻微震动,长期老化漂移低.广泛用于智能手环,蓝牙耳机,物联网传感器,家用智能面板RTC计时单元,支持全自动SMT贴片焊接,无铅RoHS合规,原厂原装货源稳定,是便携低功耗设备时钟基准优选器件.

9HT12-32.768KDZY-T,1610晶振,RTC实时时钟晶振

品牌	TXC
编码	9HT12-32.768KDZY-T
型号	9HT12晶振
频率	32.768K
精度	±20ppm
负载	7pF
尺寸	1610
工作温度	-40+85℃

9HT12-32.768KDZY-T,1610晶振,RTC实时时钟晶振

更多相关晶振参考

编码	品牌	系列	频率	频率容差	负载电容
Q 40.0-JXS11-8-10/10-FU-LF	Jauch	JXS11	40MHz	±10ppm	8pF
Q 26.0-JXS11-12-10/10-FU-LF	Jauch	JXS11	26MHz	±10ppm	12pF
Q 32.0-JXS11-8-10/10-FU-LF	Jauch	JXS11	32MHz	±10ppm	8pF
Q 50.0-JXS11-8-10/10-FU-LF	Jauch	JXS11	50MHz	±10ppm	8pF
Q 32.0-JXS11-10-10/10-FU-LF	Jauch	JXS11	32MHz	±10ppm	10pF
Q 27.120-JXS11-8-10/10-FU-LF	Jauch	JXS11	27.12MHz	±10ppm	8pF
Q 50.0-JXS11-12-10/20-T1-FU-LF	Jauch	JXS11	50MHz	±10ppm	12pF
Q 27.120-JXS11-8-10/20-T1-FU-LF	Jauch	JXS11	27.12MHz	±10ppm	8pF
Q 32.0-JXS11-10-10/20-T1-FU-LF	Jauch	JXS11	32MHz	±10ppm	10pF
Q 40.0-JXS11-12-10/10-FU-LF	Jauch	JXS11	40MHz	±10ppm	12pF
Q 40.0-JXS11-10-10/10-FU-LF	Jauch	JXS11	40MHz	±10ppm	10pF
Q 25.0-JXS11-12-10/10-FU-LF	Jauch	JXS11	25MHz	±10ppm	12pF
Q 25.0-JXS11-12-10/20-T1-FU-LF	Jauch	JXS11	25MHz	±10ppm	12pF
Q 50.0-JXS11-8-10/20-T1-FU-LF	Jauch	JXS11	50MHz	±10ppm	8pF
Q 50.0-JXS11-10-10/20-T1-FU-LF	Jauch	JXS11	50MHz	±10ppm	10pF
Q 26.0-JXS11-12-10/20-T1-FU-LF	Jauch	JXS11	26MHz	±10ppm	12pF
Q 38.40-JXS11-12-10/10-FU-LF	Jauch	JXS11	38.4MHz	±10ppm	12pF
Q 25.0-JXS11-8-10/10-FU-LF	Jauch	JXS11	25MHz	±10ppm	8pF
Q 27.120-JXS11-12-10/10-FU-LF	Jauch	JXS11	27.12MHz	±10ppm	12pF
Q 24.0-JXS11-10-10/10-FU-LF	Jauch	JXS11	24MHz	±10ppm	10pF
Q 38.40-JXS11-10-10/20-T1-FU-LF	Jauch	JXS11	38.4MHz	±10ppm	10pF
Q 38.40-JXS11-8-10/10-FU-LF	Jauch	JXS11	38.4MHz	±10ppm	8pF
Q 50.0-JXS11-10-10/10-FU-LF	Jauch	JXS11	50MHz	±10ppm	10pF
Q 40.0-JXS11-8-10/20-T1-FU-LF	Jauch	JXS11	40MHz	±10ppm	8pF
Q 27.120-JXS11-10-10/10-FU-LF	Jauch	JXS11	27.12MHz	±10ppm	10pF
Q 27.0-JXS11-12-10/10-FU-LF	Jauch	JXS11	27MHz	±10ppm	12pF
Q 26.0-JXS11-10-10/10-FU-LF	Jauch	JXS11	26MHz	±10ppm	10pF
Q 38.40-JXS11-10-10/10-FU-LF	Jauch	JXS11	38.4MHz	±10ppm	10pF
Q 27.0-JXS11-10-10/10-FU-LF	Jauch	JXS11	27MHz	±10ppm	10pF
Q 30.0-JXS11-12-10/10-FU-LF	Jauch	JXS11	30MHz	±10ppm	12pF
Q 27.0-JXS11-8-10/10-FU-LF	Jauch	JXS11	27MHz	±10ppm	8pF
Q 30.0-JXS11-10-10/10-FU-LF	Jauch	JXS11	30MHz	±10ppm	10pF
Q 26.0-JXS11-8-10/10-FU-LF	Jauch	JXS11	26MHz	±10ppm	8pF
Q 32.0-JXS11-12-10/10-FU-LF	Jauch	JXS11	32MHz	±10ppm	12pF
Q 25.0-JXS11-10-10/10-FU-LF	Jauch	JXS11	25MHz	±10ppm	10pF
Q 24.0-JXS11-12-10/10-FU-LF	Jauch	JXS11	24MHz	±10ppm	12pF
Q 24.0-JXS11-8-10/10-FU-LF	Jauch	JXS11	24MHz	±10ppm	8pF
Q 30.0-JXS11-8-10/10-FU-LF	Jauch	JXS11	30MHz	±10ppm	8pF
Q 50.0-JXS11-12-10/10-FU-LF	Jauch	JXS11	50MHz	±10ppm	12pF
Q 30.0-JXS11-12-10/20-T1-FU-LF	Jauch	JXS11	30MHz	±10ppm	12pF
Q 27.120-JXS11-12-10/20-T1-FU-LF	Jauch	JXS11	27.12MHz	±10ppm	12pF
Q 26.0-JXS11-8-10/20-T1-FU-LF	Jauch	JXS11	26MHz	±10ppm	8pF
Q 40.0-JXS11-12-10/20-T1-FU-LF	Jauch	JXS11	40MHz	±10ppm	12pF
Q 30.0-JXS11-10-10/20-T1-FU-LF	Jauch	JXS11	30MHz	±10ppm	10pF
Q 27.0-JXS11-12-10/20-T1-FU-LF	Jauch	JXS11	27MHz	±10ppm	12pF
Q 24.0-JXS11-8-10/20-T1-FU-LF	Jauch	JXS11	24MHz	±10ppm	8pF
Q 24.0-JXS11-10-10/20-T1-FU-LF	Jauch	JXS11	24MHz	±10ppm	10pF
Q 24.0-JXS11-12-10/20-T1-FU-LF	Jauch	JXS11	24MHz	±10ppm	12pF
Q 38.40-JXS11-8-10/20-T1-FU-LF	Jauch	JXS11	38.4MHz	±10ppm	8pF
Q 40.0-JXS11-10-10/20-T1-FU-LF	Jauch	JXS11	40MHz	±10ppm	10pF
Q 25.0-JXS11-10-10/20-T1-FU-LF	Jauch	JXS11	25MHz	±10ppm	10pF
Q 25.0-JXS11-8-10/20-T1-FU-LF	Jauch	JXS11	25MHz	±10ppm	8pF
Q 30.0-JXS11-8-10/20-T1-FU-LF	Jauch	JXS11	30MHz	±10ppm	8pF
Q 26.0-JXS11-10-10/20-T1-FU-LF	Jauch	JXS11	26MHz	±10ppm	10pF
Q 32.0-JXS11-8-10/20-T1-FU-LF	Jauch	JXS11	32MHz	±10ppm	8pF
Q 38.40-JXS11-12-10/20-T1-FU-LF	Jauch	JXS11	38.4MHz	±10ppm	12pF
Q 27.120-JXS11-10-10/20-T1-FU-LF	Jauch	JXS11	27.12MHz	±10ppm	10pF
Q 27.0-JXS11-8-10/20-T1-FU-LF	Jauch	JXS11	27MHz	±10ppm	8pF
Q 27.0-JXS11-10-10/20-T1-FU-LF	Jauch	JXS11	27MHz	±10ppm	10pF
Q 32.0-JXS11-12-10/20-T1-FU-LF	Jauch	JXS11	32MHz	±10ppm	12pF
