WX502系列具有超低抖动LVPECL差分晶体振荡器,WX5022C0060.000000,ECERA振荡器
DIODES百利通亚陶晶振所生产的石英晶振,贴片晶振,有源晶体,32.768KHz晶振、压电石英晶体、晶体振荡器广泛应用于智能设备,汽车电子,无线通讯,网络通信,精密仪器,GPS卫星,网络控制器,全球GPS定位系统等领域.工程、销售、仓储和物流办事处设在台北,香港、曼彻斯特、上海、深圳、中国、韩国、慕尼黑、德国、以及世界各地的支持办事处.
WX502 XO系列是具有极低抖动性能的高性能LVPECL差分晶体振荡器系列。小体积晶振尺寸5032mm，它支持各种选项，包括更宽的频率范围、2.5/3.3电压、各种稳定性和不同的封装尺寸。它旨在满足通信系统和其他高性能设备的时钟源规范
特征：
非常低的相位抖动-1.0ps RMS
更厚的晶体以提高可靠性
工业温度范围
无铅且符合RoHS标准
应用：
网络系统
服务器和存储系统
专业视频设备
测试和测量
FPGA/ASIC时钟生成
WX502系列具有超低抖动LVPECL差分晶体振荡器,WX5022C0060.000000,差分晶振,ECERA振荡器
