拉隆晶振XVO系列压控时钟振荡器,XVO793HU2-74.250–156.250,低抖动晶振,差分晶体振荡器
Raltron晶振公司成立于1983年,是全球较受欢迎的石英晶振,贴片晶振,压电石英晶体等频率产品制造商之一.从简单的音叉晶体到高稳定性的可编程晶体振荡器,Raltron提供了行业中最全面的频率管理设备.多年来,公司致力于石英晶振,贴片晶振,石英晶体振荡器,有源晶振的研究和开发,使得石英晶体,石英晶体振荡器的技术不断创新.如今Raltron晶振公司提供高性能的频率控制解决方案,在价格、质量、应用程序工程和客户支持方面满足和超越客户期望.
为了满足快速增长的无线应用市场的需求,拉隆晶振将自己打造成为一个完整的解决方案供应商,在它的石英晶体,石英水晶和晶体振荡器,贴片振荡器中添加了锯片和LTCC过滤器.该公司还为同一市场开发了一整套天线产品.
拉隆晶振XVO系列压控时钟振荡器,XVO793HU2-74.250–156.250,低抖动晶振,差分晶体振荡器
| EMTB81A3D-32.768K | CMOS | 1.8Vdc | CSP 0.8mm x 1.5mm | ±5.0ppm | 0°C to +70°C | 50 ±2(%) |
| EMTB81A8D-32.768K | CMOS | 1.8Vdc | CSP 0.8mm x 1.5mm | ±5.0ppm | -40°C to +85°C | 50 ±2(%) |
| EMTB82A3D-32.768K | CMOS | 2.5Vdc | CSP 0.8mm x 1.5mm | ±5.0ppm | 0°C to +70°C | 50 ±2(%) |
| EMTB82A8D-32.768K | CMOS | 2.5Vdc | CSP 0.8mm x 1.5mm | ±5.0ppm | -40°C to +85°C | 50 ±2(%) |
| EMTB83A3D-32.768K | CMOS | 3.3Vdc | CSP 0.8mm x 1.5mm | ±5.0ppm | 0°C to +70°C | 50 ±2(%) |
| EMTB83A8D-32.768K | CMOS | 3.3Vdc | CSP 0.8mm x 1.5mm | ±5.0ppm | -40°C to +85°C | 50 ±2(%) |
| EMTB84A3D-32.768K | CMOS | 2.8Vdc | CSP 0.8mm x 1.5mm | ±5.0ppm | 0°C to +70°C | 50 ±2(%) |
| EMTB84A8D-32.768K | CMOS | 2.8Vdc | CSP 0.8mm x 1.5mm | ±5.0ppm | -40°C to +85°C | 50 ±2(%) |
| EMTB85A3D-32.768K | CMOS | 3.0Vdc | CSP 0.8mm x 1.5mm | ±5.0ppm | 0°C to +70°C | 50 ±2(%) |
| EMTB85A8D-32.768K | CMOS | 3.0Vdc | CSP 0.8mm x 1.5mm | ±5.0ppm | -40°C to +85°C | 50 ±2(%) |
| EQTB31D1DH-32.768K | CMOS | 1.8Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | 0°C to +50°C | 50 ±10(%) |
| EQTB31D2DH-32.768K | CMOS | 1.8Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | -10°C to +60°C | 50 ±10(%) |
| EQTB31D3DH-32.768K | CMOS | 1.8Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | 0°C to +70°C | 50 ±10(%) |
| EQTB31D4DH-32.768K | CMOS | 1.8Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | -20°C to +70°C | 50 ±10(%) |
| EQTB31D5DH-32.768K | CMOS | 1.8Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | -30°C to +60°C | 50 ±10(%) |
| EQTB31D6DH-32.768K | CMOS | 1.8Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | -30°C to +75°C | 50 ±10(%) |
| EQTB31D7DH-32.768K | CMOS | 1.8Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | -30°C to +85°C | 50 ±10(%) |
| EQTB31D8DH-32.768K | CMOS | 1.8Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | -40°C to +85°C | 50 ±10(%) |
| EQTB32D1DH-32.768K | CMOS | 2.5Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | 0°C to +50°C | 50 ±10(%) |
| EQTB32D2DH-32.768K | CMOS | 2.5Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | -10°C to +60°C | 50 ±10(%) |
| EQTB32D3DH-32.768K | CMOS | 2.5Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | 0°C to +70°C | 50 ±10(%) |
快速周转(几天内发货)
非常低的抖动(典型值0.6ps)
10 MHz至1.2 GHz频率范围
可选单频或双频
稳定性低至20 ppm(-40 ~ 85℃)
可用尺寸:
7.0x5.0毫米
5.0x3.2毫米
3.2x2.5毫米
拉隆晶振XVO系列压控时钟振荡器,XVO793HU2-74.250–156.250,低抖动晶振,差分晶体振荡器
| EQTB32D4DH-32.768K | CMOS | 2.5Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | -20°C to +70°C | 50 ±10(%) |
| EQTB32D5DH-32.768K | CMOS | 2.5Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | -30°C to +60°C | 50 ±10(%) |
| EQTB32D6DH-32.768K | CMOS | 2.5Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | -30°C to +75°C | 50 ±10(%) |
| EQTB32D7DH-32.768K | CMOS | 2.5Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | -30°C to +85°C | 50 ±10(%) |
| EQTB32D8DH-32.768K | CMOS | 2.5Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | -40°C to +85°C | 50 ±10(%) |
| EQTB33D1DH-32.768K | CMOS | 3.3Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | 0°C to +50°C | 50 ±10(%) |
| EQTB33D2DH-32.768K | CMOS | 3.3Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | -10°C to +60°C | 50 ±10(%) |
| EQTB33D3DH-32.768K | CMOS | 3.3Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | 0°C to +70°C | 50 ±10(%) |
| EQTB33D4DH-32.768K | CMOS | 3.3Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | -20°C to +70°C | 50 ±10(%) |
| EQTB33D5DH-32.768K | CMOS | 3.3Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | -30°C to +60°C | 50 ±10(%) |
| EQTB33D6DH-32.768K | CMOS | 3.3Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | -30°C to +75°C | 50 ±10(%) |
| EQTB33D7DH-32.768K | CMOS | 3.3Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | -30°C to +85°C | 50 ±10(%) |
| EQTB33D8DH-32.768K | CMOS | 3.3Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | -40°C to +85°C | 50 ±10(%) |
| EQTB35D1DH-32.768K | CMOS | 3.0Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | 0°C to +50°C | 50 ±10(%) |
| EQTB35D2DH-32.768K | CMOS | 3.0Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | -10°C to +60°C | 50 ±10(%) |
| EQTB35D3DH-32.768K | CMOS | 3.0Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | 0°C to +70°C | 50 ±10(%) |
| EQTB35D4DH-32.768K | CMOS | 3.0Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | -20°C to +70°C | 50 ±10(%) |
| EQTB35D5DH-32.768K | CMOS | 3.0Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | -30°C to +60°C | 50 ±10(%) |
| EQTB35D6DH-32.768K | CMOS | 3.0Vdc | SMD 2.5mm x 3.2mm | ±5.0ppm | -30°C to +75°C | 50 ±10(%) |
拉隆晶振XVO系列压控时钟振荡器,XVO793HU2-74.250–156.250,低抖动晶振,差分晶体振荡器
Raltron晶振所生产的频率元件以及使用：
石英晶体,贴片晶振,水晶振荡子,既有插件式也有SMD贴片式,广泛使用于汽车电子,智能设备等产品中.
高精度石英晶体振荡器,普通晶体振荡器（SPXO）、压控晶体振荡器（VCXO）、温补晶体振荡器（TCXO）、恒温晶体振荡器（OCXO）等,高频率范围,低电压,低损耗的特点满足恶劣环境中使用以及产品对于电力的需求.
同步模块提供完整的时间解决方案,晶振,石英晶振,石英晶体谐振器,贴片晶振,陶瓷谐振器,声表滤波器,陶瓷滤波器等用于GPS的时钟同步,网络通讯,以及无线设备等.
